HOT STAMP for burning logo - matrix dimensions: 17x12mm - LASER - LAS031

Product description

Stamp engraved with fiber laser with extreme precision!
Details possible with fiber laser are not possible with ordinary milling machine.

Example of application: stamp for hot burning logotype in wood.

Stampdimensions: 17x12mm
imprint dimensions: 15x10mm

Other dimensions are also possible (subject to individual pricing).

MATERIAL: engraving brass
GRRAVING DEPTH: up to 0.8mm
THICKNESS: any M thread (M8 is compatible with optional burnisher)

Fibre laser metal engraving technology allows you to make:
- matrix with lots of details
- matrix with any graphic or logo
- very sharp angles of graphics which cannot be handled by ordinary milling machine
- very small matrix with lots of details
- very precise matrix
- any graphic
- convex or concave letters
- any content, numbering, symbol, graphic sign, logo.

Lead time: from 5 to 14 working days
depends on the work in progress.
For larger orders, lead time determined individually.

STAGES OF IMPLEMENTATION:
1. After purchase, please provide logo, graphics, content for engraving to the e-mail address: sklep@grawernia.pl.
- graphic files: cdr, ai, fh, wmf. for these files, please select the option: vector development NO.
- graphic files: jpg, bmp, png or tiff will have to undergo conversion to vector graphics enabling the matrix, so please select the option: vector development YES for these files.We accept only files with a resolution of at least 300dpi.
2. We send the design (2-3 designs to choose from) for approval in the form of a pdf file.
3. Once the design is approved, the matrix is made.
4. Delivery

GALLERY: includes a sample implementation

OPTIONALLY RECOMMENDED:
HOT-STAMP MIRROR - the device allows you to make a HOT-STAMP type imprint in wood. The work consists in heating the brass stamp and burning the engraved logo, graphics or text by pressing it to the wooden surface.

- the burnisher is designed for continuous operation only in the vertical position. If using a tripod, the wooden handle should be removed.
- the very good balance of the device allows comfortably long work without hand fatigue.
- the heating pin is terminated with M8 thread with a length of 10mm which allows easy replacement of stamps.

Application: burning any text or logotype in wood.

RECOMMENDATIONS: Read the instructions before turning on the device to operate the burnisher safely. The device reaches a high temperature, so be very careful during operation. We can only hold the burnisher by the wooden handles. Touching metal parts risks serious burns!!! Do not heat up the burner placed on a table, board, elements made of metal, glass, stone or flammable materials. Due to the very high operating temperature, the device should be warmed up in a safe place hanging on a hook by a steel triangular eye. After finishing work, the burnisher maintains a high temperature for a long time, so we hang it on the hook until it cools down completely. To avoid fire do not leave the device heated unattended!!!

Rated voltage: 230V~50Hz
Power consumption: 400W
Blade temperature: 450°C
Heating time to temp: 205°C depends on the dimensions of the punch
Weight: 1.2kg
Warranty: 12 months

We will be happy to answer your questions by email and phone
