Braille Handrail Plaque - size 150x36mm - gold mirror laminate - TAB582

Handrail directional sign with Braille made of engraving laminate for outdoor use. Engraving laminate is a material with increased resistance to weather conditions. We place any Braille text and an arrow in any direction on the plate. The overlays are hot-bent and designed for handrails with a diameter of 40 mm. The use of professional and licensed Braille balls makes the lettering clearly perceptible under the fingertip, all punched using CNC technology. The balls, in accordance with PZN recommendations, are positioned at a height of 0.5 mm and have a base width of 1.5 mm. The caps are fixed to the handrail with foam tape.



Before realisation, we prepare the design (PDF file) and send it to the indicated e-mail address for approval. You can contact the graphic designer at any time during the design phase. Once the design has been approved, we begin production.



The plaque is made according to the design in the gallery. Size modifications are subject to individual pricing. Feel free to contact us by phone or email: sklep@grawernia.pl for more details.



Dimensions:

- width: 150 mm

- height: 36 mm

- thickness: 1.6 mm



Material: gold, mirror laminate 1.6 mm



Colour of braille beads: transparent

Braille ball height: 0.5 mm (in accordance with PZN recommendations)
